Boolean Algebra

Boolean algebra is the method of expressing logic in a mathematical context. It is a form of symbolic logic in which variables have only two values i.e. either true (1) or false (0). The relationship between the two values is expressed by the boolean operators: AND, OR, and NOT. It is used to solve and minimize the logic equation.

Some Theorem in Boolean Algebra

If A, B, and C are three variables capable of having values 0 and 1 then, the following are some important theorems:

1.Commutation Theorems

A+B=B+A

AB=BA

2.Association Theorems

A+(B+C)=(A+B)+C

A(BC)=(AB)C

3.Distribution Theorems

A+(BC)=(A+B)(A+C)

A(B+C)=AB+AC

4.Absorption Theorems

A+AB=A

A(A+B)=A

5.De morgan’s Theorem

(A+B)’=A’B’

(AB)’=A’+B’

Basic Principle of Boolean Algebra

Three basic logic operations are named AND, OR, and NOT are discussed below:

Logic addition

(OR operation)

Logic Multiplication



(AND operation)

Inversion



(NOT operation)

0+0=0

0+1=1

1+0=1

1+1=1

0.0=0

0.1=0

1.0=0

1.1=1

(Not zero)=1

(Not one)=0



De-Morgan’s theorem

De Morgan gave two important theorems that are very helpful for simplifying the logic expressions.

First theorem:

It states that the complement of a sum equals the product of complements.

Mathematically, (A+B)’=A’.B’

Second theorem:

It states that the complement of the product equals the sum of the complements.

Mathematically, (AB)’=A’+B’

The above theorem can be verified by using truth table. For the truth table, we use a binary number system i.e. both A and B can have value either 0 or 1.

A

B A’ B’ A+B (A+B)’ A.B (A.B)’ A’+B’ A’.B’




0

0

1

1







0

1

0

1







1

1

0

0



1



0

1

0

0



1

1

1

1



0

0

0

0



0

0

1

1



1

1

0

1



1

1

0

1

0

0

0

From the truth table,

(A+B)’=A’.B’ and (AB)’=A’+B’

Hence, De-Morgan’s theorem is verified.
